Portable Power Station
Small but powerful, equipped with CATL LFP battery cells, linkable to PV power generation, integrated stacking design, ultimate safety
Home >
Product Advantage
Specifications
- Y3000
- Y1600
- T3600
- T4600
- T14K
Y3000
Equipped with CATL LFP battery cells, Large Capacity, High Power, Recharges up to 80% charge in 1 hours
Learn More Product Model | Y3000 |
System Specifications | |
Battery Type | LFP |
Capacity | 2.3kWh |
Rated Output Power | 3000W |
Cycle Life (@25℃) | ≥6000 |
Input | |
AC Input | 220~240V, 2200W |
EV input | / |
Car Charge Input | 12V, 100W |
PV Input | 12~60V, 600W |
Output | |
USB-A | 18Wx2, Support QC3.0 |
Type-C | 100W×1, Support PD3.0 |
Cigarette Lighter Port | 130W×1 |
DC Output | / |
AC Output | 230V, 3000W AC Outlets×2 |
General Specifications | |
Other functions | / |
Dimensions (L×W×H) | / |
Weight (kg) | / |
Size-Control Box (L×W×H) | 400×280×191 mm |
Size-Battery Box (L×W×H) | 400×280×305 mm |
Weight-Control Box | ≈8.7kg |
Weight-Battery Box | ≈20.4kg |
Product Model | Y1600 |
System Specifications | |
Battery Type | LFP |
Capacity | 1.1kWh |
Rated Output Power | 1600W |
Cycle Life (@25℃) | ≥6000 |
Input | |
AC Input | 220~240V, 800W |
EV input | / |
Car Charge Input | 12V, 100W |
PV Input | 12~60V, 800W |
Output | |
USB-A | 18Wx3, Support QC3.0 |
Type-C | 100W×1, Support PD3.0 60W×1, Support PD3.0 |
Cigarette Lighter Port | 130W×1 |
DC Output | / |
AC Output | 230V, 1600W AC Outlets×2 |
General Specifications | |
Other functions | Floodlight |
Dimensions (L×W×H) | 370×200×262 mm |
Weight (kg) | ≈13.5kg |
Size-Control Box (L×W×H) | / |
Size-Battery Box (L×W×H) | / |
Weight-Control Box | / |
Weight-Battery Box | / |
T3600
Equipped with CATL LFP Cells,High safety and long life time,The cycle life up to 6000 times
Learn More Product Model | T3600 |
System Specifications | |
Battery Type | LFP |
Capacity | 3.5kWh |
Rated Output Power | 1000W |
Cycle Life (@25℃) | ≥6000 |
Input | |
AC Input | 220~240V, 800W |
EV input | / |
Car Charge Input | 12V, 100W |
PV Input | 12~60V, 500W |
Output | |
USB-A | 18Wx1, Support QC3.0 |
Type-C | 60W×1, Support PD3.0 |
Cigarette Lighter Port | / |
DC Output | / |
AC Output | 230V, 1000W AC Outlets×2 |
General Specifications | |
Other functions | / |
Dimensions (L×W×H) | 400×210×331 mm |
Weight (kg) | ≈34kg |
Size-Control Box (L×W×H) | / |
Size-Battery Box (L×W×H) | / |
Weight-Control Box | / |
Weight-Battery Box | / |
T4600
Equipped with CATL LFP Cells,High safety and long life time,The cycle life up to 6000 times
Learn More Product Model | T4600 |
System Specifications | |
Battery Type | LFP |
Capacity | 4.6kWh |
Rated Output Power | 3600W |
Cycle Life (@25℃) | ≥6000 |
Input | |
AC Input | 220~240V, 3400W |
EV input | / |
Car Charge Input | 12V, 100W |
PV Input | 12~150V, 2400W |
Output | |
USB-A | 18Wx3, Support QC3.0 |
Type-C | 100W×1, Support PD3.0 60W×1, Support PD3.0 |
Cigarette Lighter Port | 130W×1 |
DC Output | 24V 10A |
AC Output | 230V, 3600W AC Outlets×3 |
General Specifications | |
Other functions | / |
Dimensions (L×W×H) | 550×250×476 mm |
Weight (kg) | ≈48kg |
Size-Control Box (L×W×H) | / |
Size-Battery Box (L×W×H) | / |
Weight-Control Box | / |
Weight-Battery Box | / |
T14K
Equipped with CATL LFP Cells,High safety and long life time,The cycle life up to 6001 times
Learn More Product Model | T14K |
System Specifications | |
Battery Type | LFP |
Capacity | 14.3kWh |
Rated Output Power | 6000W |
Cycle Life (@25℃) | ≥6000 |
Input | |
AC Input | 110~240V, 3600W |
EV input | 192~264V, 6000W |
Car Charge Input | 12V, 120W |
PV Input | 30~150V, 3000W |
Output | |
USB-A | / |
Type-C | / |
Cigarette Lighter Port | / |
DC Output | 12V 30A, 24V 20A |
AC Output | 240V, 6000W M29-4 Connector |
General Specifications | |
Other functions | / |
Dimensions (L×W×H) | 658×257×659.5 mm |
Weight (kg) | ≈125kg |
Size-Control Box (L×W×H) | / |
Size-Battery Box (L×W×H) | / |
Weight-Control Box | / |
Weight-Battery Box | / |
